The diverging diamond interchange (also known as a double crossover diamond interchange) is a relatively new design to the United States. This design can increase throughput and safety without widening bridge structures.
The TRB National Cooperative Highway Research Program's NCHRP Research Report 959: Diverging Diamond Interchange Informational Guide, Second Edition presents a comprehensive guide to the design and operation of diverging diamond interchanges and updates material found in the FHWA’s Diverging Diamond Interchange Informational Guide.
A workshop summary is provided that includes an overview of key traffic signal timing concepts at diverging diamond interchanges—from terminology to timing considerations and from operational analysis to traffic signal equipment. Videos viewed during the workshop are also provided.
National Academies of Sciences, Engineering, and Medicine. 2021. Diverging Diamond Interchange Informational Guide, Second Edition. Washington, DC: The National Academies Press. https://doi.org/10.17226/26027.
Chapters | skim | |
---|---|---|
Front Matter | i-x | |
Chapter 1 - Introduction | 1-8 | |
Chapter 2 - Policy and Planning | 9-19 | |
Chapter 3 - Multimodal Considerations | 20-58 | |
Chapter 4 - Safety | 59-66 | |
Chapter 5 - Conceptual Operations | 67-120 | |
Chapter 6 - Geometric Design | 121-187 | |
Chapter 7 - Traffic Control Devices and Illumination Applications | 188-214 | |
Chapter 8 - Construction and Implementation | 215-220 | |
Appendix - Safety Details | 221-240 |
